Arc flashes are nothing to joke about as the effect of incident energy can be life-threatening. The progression of an arc flash event starts with an arc fault, which is essentially a short circuit conducted between two live parts, or by one live part and one ground, creating ionized air. The next event in this progression is referred to as the arc flash. Think of an arc flash as the extreme heat and blinding light produced by the arc fault. If the conditions are right, an arc flash can reach the final stage and result in an enormous electrical explosion known as an arc blast. This supersonic shockwave is the result of the arc flash and the newly ionized air vaporizing any metal conductors within the unit. The traumatic force of an arc blast can severely injure or be deadly to those in the near vicinity as well as damage just about everything nearby.
Definitions aside, this article will discuss the specific dangers associated with this type of accident, and ultimately explain how to protect workers and prevent arc flashes all together.
What Happens During an Arc Flash?
Electrical arcing begins when the electricity exits its intended path and begins traveling through the air toward a grounded area. Once this happens, it ionizes the air, which further reduces the overall resistance along the path that the arc is taking. This helps draw in additional electrical energy.
The electric arc will travel toward a ground of some type, which will typically be whatever object is closest to its source. The exact distance that an arc flash can travel is known as the arc flash boundary. This is determined by the potential energy present and a variety of other factors such as air temperature and humidity.
How Long Does an Arc Flash Last?
An arc flash can last anywhere from a fraction of a second to several seconds, depending on a number of factors. Most arc flashes don't last very long because the source of the electricity is cut off quickly by circuit breakers or other safety equipment. The most advanced systems today use devices known as arc eliminators, which detect and extinguish the arc within just a few milliseconds.
If a system does not have any type of safety protection, however, the arc flash will continue until the flow of electricity is physically stopped. This may occur when a worker physically cuts the power to the area or when the damage caused by the arc flash becomes severe enough to somehow stop the flow of electricity.
What Causes an Arc Flash?
In most cases, the root cause of an arc flash will be a damaged piece of equipment such as a wire. It could also be a result of someone working on equipment, which makes it possible for the electricity to escape from the path it is normally confined to.
Electricity is always going to follow the path of least resistance. This is why an arc flash will not necessarily happen as soon as something is damaged, or an alternate path is made available. Instead, the electricity will continue down the intended path until another option that has less resistance becomes available.
The following are some examples that can create a path with lower resistance, and therefore cause an arc flash:
- Dust - In dusty areas the electricity may begin passing outside the wiring or other equipment through dust.
- Dropped Tools - If a toolis dropped onto a wire, for example, it can damage it and allow the electricity to pass into the tool. From there, it must find another path to continue on.
- Accidental Touching - If a person touches the damaged area, the electricity may travel through his or her body, or at least out of the normal path.
- Condensation - When condensation forms, electricity may escape the wiring through the water.
- Material Failure - If a wire is damaged to the point where the electricity has trouble passing through, the path may be more resistant than going outside of the wire.
- Corrosion - Corrosion can create a path outside the wire.
- Faulty Installation - When equipment is installed improperly it can make it difficult or impossible for electricity to follow the intended path.
Potential Damages of an Arc Flash
Due to high temperatures of up to 35,000°F, intense blasts, and other results of an arc flash, these electrical mishaps can cause a lot of damage very quickly. Understanding the different types of damage that can occur can help facilities plan their safety efforts. The following are all examples of what an arc flash or arc blast are capable of.
Potential Property Damage:
- Heat - The heat from an arc flash can easily melt metal, which can damage expensive machines and other equipment.
- Fire - The heat from these flashes can quickly cause a fire, which can spread through a facility if not stopped.
- Blasts - Arc blasts can break windows, splinter wood in the area, and even bend metal. Anything stored within the arc blast radius can be damaged or destroyed in just seconds.
Potential Human Injury:
- Burns - Second and third-degree burns can occur in a fraction of a second.
- Electrocution - Depending on the amount of electricity, where it enters the body, and where it leaves, electrocution can be fatal.
- Auditory Damage - Arc flashes are capable of producing extremely loud noises, which can cause permanent hearing damage.
- Eyesight Damage - Arc flashes can be very bright, which can cause temporary or even long-term damage to the eyes.
- Arc Blast Damage - An arc blast can create a force that is thousands of pounds per inch. This can knock a person back several feet. It can also cause broken bones, collapsed lungs, and concussions.
Wearing personal protective equipment can provide a significant amount of arc fault protection, but it cannot eliminate all risk. Workers who are present when an arc flash occurs are always at risk, no matter the PPE they are wearing. This is why it is important to de-energize a machine before it is worked on whenever possible.
Workplace Organization Guide: Learn simple strategies for long-term success
When your workplace is cluttered, methods aren’t as efficient as they could be. This free Quick Guide to an Organized Workplace covers simple tools and strategies you and your team can use to keep workbenches, storage areas, work cells, and other locations organized and looking professional.
Arc Flash Safety Requirements
Companies with electrical equipment need to take arc flash safety seriously. There are a variety of measures that can reduce the chances of an arc flash occurring and keep people as safe as possible if one does happen.
All facilities must consider the various arc flash safety standards that have been put in place by government and private institutions. Determining which standards to follow can help ensure a facility is in compliance with area rules and regulations, in addition to minimizing incidents.
The following are the most common standards that cover arc flash safety in the United States:
- OSHA - 29 CFR parts 1910 and 1926 cover requirements for electrical power generation, transmission, and distribution.
- NFPA - NFPA 70, the National Electrical Code (NEC) pertains to safe electrical installation and practices. NFPA 70E, the Standard for Electrical Safety in the Workplace, details a variety of requirements for warning labels regarding arc flashes and arc blasts. It also offers recommendations on implementing workplace best practices to help keep employees who work around high voltage equipment safe.
- IEEE 1584 - This is a set of guidelines for accurately calculating arc-flash hazards.
Preventing an Arc Flash
The first step in arc flash protection is minimizing the risk of one occurring. This can be done by completing an electrical risk assessment, which can help identify where the biggest dangers are in a facility. Following IEEE 1584 is a good option for most facilities by helping to identify common problems.
Routine inspections of all high voltage equipment such as electrical switchboards, panelboards, control panels, socket enclosures, motor control centers, and all wiring are essential. If there is any sign of corrosion, damage to wires, or other issues, they should be fixed as soon as possible. This will help keep the electrical currents safely contained within the machines and wires where they belong.
Proper Labeling Efforts
Anywhere in a facility where high electrical currents can exist should be properly labeled with arc flash warning labels. These can be purchased pre-made or printed with any industrial label printer as they are needed. The National Electrical Code article 110.16 clearly states that this type of equipment needs to be marked to warn workers of the risks.
De-Energizing Equipment when Performing Maintenance
Whenever a machine needs to be worked on in any way, it should be completely de-energized. De-energizing a machine is more than just turning it off. All machines should be shut down and physically disconnected from any power source. Once disconnected, a voltage check should also be done to ensure there is no latent energy stored away.
Ideally, a lockout/tagout policy should be in place, which will put a physical lock on the electrical supply so that it cannot be accidentally plugged back in while someone is working on it.
Arc Flash Personal Protection Equipment (PPE)
It should be very rare, but there are some cases when machines must be worked on while they are still energized. When this is the case, all employees working in the area should be required to wear proper personal protective equipment such as safety goggles, hearing protection, voltage rated gloves, and arc-rated clothing.
The specific PPE that is worn should correspond to the maximum potential risk based on the amount of electricity going through the machine. Having head to toe personal protective equipment can help to prevent serious incidents or even fatality should an arc flash occur while the machine is being worked on.
Whenever possible, circuit breakers should be put in place on all machines. These breakers will quickly detect when there is a sudden surge in electricity being drawn and stop the flow immediately. Even with circuit breakers, an arc flash can occur, but it will only last a fraction of the time since the electrical current will be cut off. However, the severity of just a very brief arc flash can be deadly. For this reason, circuit breakers should not be seen as a sufficient arc flash safety program.
Additional Arc Flash facts:
- An arc flash is a phenomenon where a flashover of electric current leaves its intended path and travels through the air from one conductor to another, or to ground. The results are often violent and can cause serious injury or death. Source: https://www.osha.gov/sites/default/files/2018-12/fy07_sh-16615-07_arc_flash_handout.pdf
- An arc flash can produce temperatures as high as 35,000°F, which is nearly seven times hotter than the surface of the sun. The intense heat can vaporize nearby materials and cause severe burns. Source: https://en.wikipedia.org/wiki/Arc_flash
- An arc flash can also generate a powerful blast pressure, flying objects, and a loud sound blast. The blast pressure can reach up to 2,000 lbs/sq.ft, which can knock down workers and damage equipment. The flying objects can include molten metal and shrapnel, which can penetrate the skin or eyes. The sound blast can reach up to 140 dB, which is as loud as a gun and can cause hearing loss. Source: https://www.osha.gov/sites/default/files/2018-12/fy07_sh-16615-07_arc_flash_handout.pdf
- The severity of an arc flash injury depends on several factors, such as the proximity of the worker to the hazard, the temperature, and the time for the circuit to break. The National Fire Protection Association (NFPA) has developed specific approach boundaries to protect workers from the risk of arc flash. These boundaries are: flash protection boundary, limited approach, restricted approach, and prohibited approach. Source: Arc flash - Wikipedia
- The best way to prevent arc flash injuries is to de-energize the circuit before working on it. However, if it is not feasible to do so, workers should follow safety-related work practices, such as wearing appropriate personal protective equipment (PPE), using insulated tools, and maintaining a safe distance from the live parts. Source: Information and Discussion Topics for Electrical Workers
- According to the Occupational Safety and Health Administration (OSHA), arc flash is one of the leading causes of electrical fatalities in the U.S. Between 2012 and 2016, there were 156 fatal electrical injuries involving arc flash, accounting for 46% of all electrical fatalities. Source: https://lni.wa.gov/safety-health/safety-research/files/2006/ArcFlashHazardReport.pdf
